Width:
84mm
Height:
46mm
Length:
167mm
Weight:
550g
True RMS:
Yes
Calibrated:
UKAS
Dimensions:
167 x 84 x 46mm
Application:
Electrical
Battery Type:
9V
Display Type:
Digital
Model Number p:
117
Multimeter Type:
Handheld
Maximum Frequency:
1kHz
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
Safety Category Level:
CAT III
Safety Category Voltage:
600V
Best AC Current Accuracy:
±1.5% + 3 Digits
Best AC Voltage Accuracy:
±1% + 3 Digits
Best DC Current Accuracy:
±1% + 3 Digits
Best DC Voltage Accuracy:
±0.5% + 2 Digits
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
-10°C
AC Current Measurement Resolution:
0.001A ac
AC Voltage Measurement Resolution:
0.1mV ac
DC Current Measurement Resolution:
0.001A dc
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
Capacitance Measurement Resolution:
1nF
Best Resistance Measurement Accuracy:
±1.5% + 2 Digits
Best Capacitance Measurement Accuracy:
±1.9% + 2 Digits
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
40MΩ
Absolute Maximum Capacitance Measurement:
9.999F
