Width:
50mm
Height:
203mm
Length:
100mm
Weight:
610g
True RMS:
Yes
Calibrated:
UKAS
Dimensions:
100 x 50 x 203mm
Battery Type:
AA Alkaline IEC/EN LR6
Display Type:
Digital
Model Number p:
787B
Multimeter Type:
Handheld
Maximum Frequency:
19.99kHz
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Diode, Loop, Resistance
Safety Category Level:
CAT III, CAT IV
Safety Category Voltage:
600 V, 1000V
Best AC Current Accuracy:
±1 % of 2 Reading + Count
Best AC Voltage Accuracy:
±0.7 % of 4 Reading + Count
Best DC Current Accuracy:
±0.05 % of 2 Reading + Count
Best DC Voltage Accuracy:
±0.1 % of 1 Reading + Count
Maximum Operating Temperature:
+55°C
Minimum Operating Temperature:
-20°C
AC Current Measurement Resolution:
0.001A ac
AC Voltage Measurement Resolution:
0.1mV ac
DC Current Measurement Resolution:
0.001mA dc
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
Best Resistance Measurement Accuracy:
±0.2 % of 2 Reading + Count
Absolute Maximum AC Current Measurement:
1A ac
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Current Measurement:
1A dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
40MΩ
