Width:
101mm
Height:
215mm
Length:
60mm
Weight:
698.5g
True RMS:
Yes
Calibrated:
UKAS
Dimensions:
6 x 10.1 x 21.5cm
Battery Type:
AA
Display Type:
Digital
Model Number p:
87V-MAX
Multimeter Type:
Handheld
Maximum Frequency:
199.99kHz
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Resistance, Temperature
Safety Category Level:
CAT III, CAT IV
Safety Category Voltage:
600 V, 1000V
Best AC Current Accuracy:
±0.7 % + 4 digits
Best AC Voltage Accuracy:
±0.7% + 4 digit
Best DC Current Accuracy:
±0.2% + 2 digit
Best DC Voltage Accuracy:
±0.05% + 1 digit
Maximum Operating Temperature:
+55°C
Minimum Operating Temperature:
-15°C
AC Current Measurement Resolution:
0.1µA ac
AC Voltage Measurement Resolution:
0.1mV ac
DC Current Measurement Resolution:
0.1µA dc
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
Capacitance Measurement Resolution:
0.01nF
Best Resistance Measurement Accuracy:
±(0.2% + 1)
Best Capacitance Measurement Accuracy:
±1% + 2 digit
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
50MΩ
Absolute Maximum Capacitance Measurement:
9.999mF
Absolute Maximum Temperature Measurement:
+1090 °C, +1994°F
