Width:
335mm
Height:
100mm
Length:
225mm
Weight:
2.5kg
True RMS:
Yes
Dimensions:
225 x 335 x 100mm
Display Type:
Digital
Model Number p:
2831E
Multimeter Type:
Bench
Maximum Frequency:
1MHz
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance
Safety Category Level:
CAT I, CAT II
Safety Category Voltage:
300 V, 1000V
Best AC Current Accuracy:
±2 %
Best AC Voltage Accuracy:
±3 %
Best DC Current Accuracy:
±0.3 %
Best DC Voltage Accuracy:
±0.04 %
AC Current Measurement Resolution:
1mA ac
AC Voltage Measurement Resolution:
1mV ac
DC Current Measurement Resolution:
1mA dc
DC Voltage Measurement Resolution:
1mV dc
Resistance Measurement Resolution:
1Ω
Best Resistance Measurement Accuracy:
±0.3 %
Absolute Maximum AC Current Measurement:
20A ac
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum DC Current Measurement:
20A dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
20MΩ
