Width:
93mm
Height:
47.5mm
Length:
207mm
Weight:
487.5g
True RMS:
Yes
Dimensions:
207 x 93 x 47.5mm
Battery Type:
AA
Display Type:
Digital
Model Number p:
3000 FC
Multimeter Type:
Handheld
Maximum Frequency:
99.99kHz
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Temperature
Safety Category Level:
CAT III, CAT IV
Safety Category Voltage:
600 V, 1000V
Best AC Current Accuracy:
1.5 %
Best AC Voltage Accuracy:
1 %
Best DC Current Accuracy:
0.5 %
Best DC Voltage Accuracy:
0.09 %
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
-10°C
AC Current Measurement Resolution:
0.01mA ac
AC Voltage Measurement Resolution:
0.1mV ac
DC Current Measurement Resolution:
0.01mA dc
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
Capacitance Measurement Resolution:
1nF
Best Resistance Measurement Accuracy:
0.5 %
Best Capacitance Measurement Accuracy:
1.2 %
Absolute Maximum AC Current Measurement:
400mA ac
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Current Measurement:
400mA dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
50MΩ
Absolute Maximum Capacitance Measurement:
9.999F
