Width:
12mm
Height:
112mm
Length:
56mm
Weight:
100g
True RMS:
No
Calibrated:
UKAS
Dimensions:
56 x 12 x 112mm
Battery Type:
LR44 1.5 V
Display Type:
Digital
Model Number p:
IDM5A
Multimeter Type:
Handheld
Maximum Frequency:
40kHz
Functions Measured:
AC Current, AC Voltage, Capacitance, Conductance, DC Current, DC Voltage, Diode, Frequency, Resistance, RMS, Temperature
Safety Category Level:
CAT II, CAT III
Safety Category Voltage:
300 V, 600V
Best AC Current Accuracy:
±0.9% + 5 Digits
Best AC Voltage Accuracy:
±0.9% + 5 Digits
Best DC Current Accuracy:
±0.9% + 5 Digits
Best DC Voltage Accuracy:
±0.6% + 2 Digits
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
0°C
AC Current Measurement Resolution:
0.1µA ac
AC Voltage Measurement Resolution:
0.1mV ac
DC Current Measurement Resolution:
0.1µA dc
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
Capacitance Measurement Resolution:
0.01nF
Best Resistance Measurement Accuracy:
±0.9% + 2 Digits
Best Capacitance Measurement Accuracy:
±2.9% + 5 Digits
Absolute Maximum AC Current Measurement:
4mA ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Current Measurement:
4mA dc
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
40MΩ
Absolute Maximum Capacitance Measurement:
400µF
