Width:
31 (Without Holster) mm, 50 (With Holster) mm
Height:
175 (Without Holster) mm, 192 (With Holster) mm
Length:
84 (without Holster) mm, 95 (with Holster) mm
Weight:
550 (With Holster)g
True RMS:
No
Calibrated:
UKAS
Dimensions:
84 x 31 x 175 (without Holster) mm, 95 x 50 x 192 (with Holster) mm
Battery Type:
9V, IEC 6F22, NEDA 1604
Display Type:
Digital
Model Number p:
IDM91E
Multimeter Type:
Handheld
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode, Resistance
Safety Category Level:
CAT III
Safety Category Voltage:
600V
Best AC Current Accuracy:
±2.5% + 3 Digits
Best AC Voltage Accuracy:
±1.25% + 4 Digits
Best DC Current Accuracy:
±1% + 1 Digits
Best DC Voltage Accuracy:
±0.5% + 1 Digits
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
0°C
AC Current Measurement Resolution:
0.1µA ac
AC Voltage Measurement Resolution:
0.1mV ac
DC Current Measurement Resolution:
0.1µA dc
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
Best Resistance Measurement Accuracy:
±0.75% + 1 Digits
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
20MΩ
