Width:
502.9mm
Height:
88.9mm
Length:
425.5mm
Weight:
12kg
True RMS:
Yes
Dimensions:
425.5 x 502.9 x 88.9mm
Display Type:
Digital
Model Number p:
3458A
Multimeter Type:
Bench
Maximum Frequency:
10MHz
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance
Best AC Current Accuracy:
1 % Reading + 0.04 % Range
Best AC Voltage Accuracy:
20 % Reading + 0.08 % Range
Best DC Current Accuracy:
115 ppm Reading + 10 ppm Range
Best DC Voltage Accuracy:
14 ppm Reading + 3 ppm Range
Maximum Operating Temperature:
+55°C
Minimum Operating Temperature:
0°C
AC Current Measurement Resolution:
100µA ac
AC Voltage Measurement Resolution:
10mV
DC Current Measurement Resolution:
100nA
DC Voltage Measurement Resolution:
100mV
Absolute Maximum AC Current Measurement:
1A ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Current Measurement:
1A dc
Absolute Maximum DC Voltage Measurement:
600V dc
