Width:
250mm
Height:
125mm
Length:
100mm
Weight:
1.3 (with Battery)kg
IP Rating:
IP40
Plug Type:
UK
Test Type:
Continuity, Frequency, Insulation Resistance, Loop and Line Resistance, Measure Motor Windings, Phase Sequence Test, Prospective Earth Fault Current, Prospective Short Circuit Current, RCD Test, Resistance, Voltage, Wiring Polarity
Calibrated:
UKAS
Dimensions:
100 x 250 x 125mm
Battery Type:
AA
Non-Tripping:
No
Power Source:
Battery
RCD Ramp Test:
Yes
RCD Test Type:
A, AC
Model Number p:
1662
Test Standards:
IEC 60364
Safety Category:
CAT III 500 V, CAT IV 300 V
Downloadable Data:
Yes
Automatic RCD Test:
Yes
Remote Switch Mode:
Yes
Safety Category Level:
CAT III, CAT IV
Continuity Test Current:
10mA
Insulation Test Voltage:
100 V, 250 V, 500 V, 1000V
Safety Category Voltage:
300 V, 500 V
Loop Impedance Test Type:
Phase to Earth, Phase to Neutral
Voltage Measurement Range:
100 → 1000V
Maximum Voltage Measurement:
500V ac/dc
Maximum Continuity Resistance:
2000Ω
Minimum Continuity Resistance:
20Ω
